Air-gap achromatic design
Wavelength range: 405-1650nm
PC, APC, SMA interfaces optional

Long Distance Collimator The fiber optic beam can be collimated and shaped for different lasers output through fiber optic connections, providing diffraction-limited performance at the design wavelength, with a collimation distance of up to 200 meters. The structure of this series of collimators is compact. Aberration correction is performed during design by selecting an air-spaced doublet lens series, which has excellent collimation effect and ability to couple space light. The effective focal length of the doublet lens depends on the wavelength. Therefore, this series of collimators should be used at the design wavelength for optimal performance.
Features：
Three Connector Options：FC/PC、FC/APC、SMA905
Maintain good collimation characteristics within a range of 200 meters.
Compact structure, Convenient for installation
Custom Options including wavelengths
It is recommended to select Ysenser's standard patch cords to improve the repeatability and consistency of the parameters.


Air-gap achromatic design
Wavelength range: 405-1650nm
PC, APC, SMA interfaces optional

Large Beam Collimators  By using an air gap bonded lens, it can provide better beam quality than aspherical lenses and achromatic lenses in terms of collimation performance. The design of a low aberration lens group can achieve a beam closer to a Gaussian beam, with smaller divergence angles and smaller wavefront errors.
Features：
Three Connector Options：FC/PC、FC/APC、SMA905
Compatible with Narrow and Wide Key Connectors
Compact structure, Convenient for installation
Custom Options including wavelengths
It is recommended to select Ysenser's standard patch cords to improve the repeatability and consistency of the parameters.


M2 approaches 1
Excellent wavefront error design
Wavelength range: 450-1650nm
Collimation distance ≥ 2km

Ultra-Long-Range Collimator Designed for ultra-long-distance applications, this collimator boasts an impressive collimation distance surpassing 1000 meters. It ensures the laser beam maintains high collimation throughout extended transmission, minimizing energy divergence and concentrating energy effectively. This significantly boosts laser transmission efficiency and positioning precision.
With a focal length exceeding 300 mm, the collimator excels at focusing spatial lasers. Its precise focusing mechanism enables efficient coupling of more laser energy into optical fibers, perfectly suiting demanding scenarios like long-distance diffuse reflection testing.
Featuring a 100-mm large aperture, the collimator facilitates smooth passage of increased laser energy, substantially enhancing the system's luminous flux. Besides augmenting laser power and intensity, the large aperture optimizes beam imaging quality and reduces wave aberration, providing robust support for overall system performance enhancement.
Application：
Long-distance laser communication reduces signal attenuation and interference, enabling high-speed and large-capacity data transmission.
In laser surveying and mapping for terrain and architecture, lasers' high collimation and precise ranging yield high-precision 3D terrain and building data.
It can be paired with high-energy lasers, functioning as a transmitting or ranging lens
